　　關風機入口/出口：入口為圓口并配有透明視窗，以便觀察物料的流動狀況;出口為方形增大了出口面積使物料順利排出?！　∑胀ㄐ停航Y(jié)構緊湊，占用空間小?！　≥S承外置式：防止粉塵侵入軸承、增大適應溫度的范圍?！　≥S承外置式安裝、性能優異?！　◎?qū)動方式：馬達直聯驅動為主、鏈驅動?！　￡P(guān)風機材質：碳鋼、鑄鐵、不銹鋼、陶瓷、尼龍、四氟、特氟龍、鈦合金、鋁合金、各種合金系列等?！倦娫?微信咨詢：陳經理18068546632】　　關風機的安裝：　　1、檢查產品經過運輸或貯藏后是否損壞銹蝕;葉輪應能靈活轉動?！　?、與關風器的結合平面應平整，平面度不大于0.5mm，以免機殼變形引起故障?！　?、關風器安裝后要校正水平，緊固固定螺栓，葉輪能靈活轉動無障礙。【電話/微信咨詢：陳經理18068546632】　　我公司專 業生產(B)GFY、YJD系列關風機(關風器)、星型卸料器、DS系列電動鎖氣器、DN型旋轉閥，快開閥、清潔閥、風送式旋轉閥等產品。廣泛應用于鋰電池、糧食、飼料、石油化工、制藥、淀粉、油脂、化工干燥、塑料、除塵、冶金、環保、電子、煤炭、建筑、電力機械等行業設備上。用于固體粒料、粉料、超微粉體在氣力輸送及管網正負壓狀態下的卸料。           《掃二維碼-添加 陳經理 微信-咨詢風送式關風機》　　Shut down the inlet/outlet of the fan: The inlet is circular and equipped with a transparent window for observing the flow of materials; The square shape of the outlet increases the outlet area and facilitates the smooth discharge of materials.　　Ordinary type: compact structure and small space occupation.　　External bearing: prevents dust from entering the bearing and increases the temperature adaptability range.　　External installation of bearings, excellent performance.　　Drive mode: mainly direct motor drive, chain drive.　　Material of the fan: carbon steel, cast iron, stainless steel, ceramic, nylon, PTFE, PTFE, titanium alloy, aluminum alloy, various alloy series, etc.　　Installation of shutdown fan:　　1. Check whether the product is damaged or corroded after transportation or storage; The impeller should be able to rotate flexibly.　　2. The joint plane with the air conditioner should be flat, with a flatness of no more than 0.5mm, to prevent deformation of the casing and potential malfunctions.　　3. After the installation of the air conditioner, it is necessary to calibrate the level, tighten the fixing bolts, and ensure that the impeller can rotate flexibly without obstacles.

　　【偏置式星型卸料器系列】　　適用于≤2kg/cm2系統壓力或壓差。　　設置排氣口(正壓輸送時選用)將葉輪旋轉帶出的氣體通過排氣口送至排氣裝置，提高填充效率?！　∑眯读掀鞣狼辛先肟谠O(shè)計，即便上游充滿物料也可安全啟動。　　偏置式進出料口設計，減少了物料的破碎與損壞?！倦娫?微信咨詢：陳經理18068546632】　　軸承外置式安裝、經久耐用、性能優異?！　√峁╂滘?qū)動、直聯驅動多種安裝方式?！　「鶕?jù)需求配置減速機電機?！　∑眯读掀鞑馁|(zhì)主要有：鑄鋼、不銹鋼、合金系列等。　　殼體及主要零部件采用精密鑄造，外形美觀;　　高強度的閥體及軸，可承受高壓且運轉平穩;　　特殊防卡料設計，避免運轉中粒子剪斷現象;【電話/微信咨詢：陳經理18068546632】　　常州同得利機械廠擁有多年的研發生產/定制卸料閥旋轉閥的經驗，秉承質量第 一、用戶至 上的原則。我們的旋轉閥能夠處理鋰電池、鋼廠、電廠、水泥、礦山、環保、塑料、化工、食品和醫藥等行業的各種顆粒、片狀、塊狀物料、粘料、粉料、超微粉體等。       《掃二維碼-添加 陳經理 微信-咨詢偏置式卸料器》　　Offset star shaped unloader series　　Suitable for system pressures or pressure differentials of ≤ 2kg/cm 2.　　Set up an exhaust port (selected for positive pressure conveying) to send the gas carried out by the impeller rotation to the exhaust device through the exhaust port, improving the filling efficiency.　　The offset unloader is designed with an anti cutting material inlet, which can be safely started even if the upstream is filled with material.　　The offset inlet and outlet design reduces material breakage and damage.　　External installation of bearings, durable and excellent performance.　　Provide multiple installation methods for chain drive and direct drive.　　Configure the gearbox motor according to the requirements.　　The materials of offset unloaders mainly include cast steel, stainless steel, alloy series, etc.　　The shell and main components are precision cast, with a beautiful appearance;　　High strength valve body and shaft, capable of withstanding high pressure and running smoothly;　　Special anti jamming material design to avoid particle shearing during operation.

　　星型卸料器/卸料閥是氣力輸送系統中的關鍵設備。也是除塵和加料系統的常用設備。根據特性、用途和使用條件的不同，星型卸料器有多種結構型式，星型卸料器的選型要根據被輸送物料的特性如堆積密度、物料溫度、吸潮性、含水量、粒徑、流動性、硬度、腐蝕性等來決定的?！　〕Ｖ萃美麢C械廠主要制造適用于粘性的，含堅硬雜質的以及高溫高壓或高真空情況下使用的特殊結構的星型卸料器。以及超小尺寸的卸料器，都是非常規結構特殊非標定制?！倦娫?微信咨詢：陳經理 18068546632】　　不銹鋼卸料器可應用于食品等有高衛生要求的場合，拆卸方便，易于進行清理工作，符合高要求的衛生標準。操作方便，無死點。     《掃二維碼-添加 陳經理 微信-咨詢食品級卸料閥》　　Star shaped unloader/discharge valve is a key equipment in pneumatic conveying systems. It is also a commonly used equipment for dust removal and feeding systems. According to different characteristics, purposes, and usage conditions, star shaped unloaders have various structural types. The selection of star shaped unloaders should be determined based on the characteristics of the conveyed material, such as bulk density, material temperature, moisture absorption, moisture content, particle size, flowability, hardness, corrosiveness, etc.　　Changzhou Tongdeli Machinery Factory mainly manufactures star shaped unloaders with special structures suitable for viscous, hard impurity containing, and high-temperature, high-pressure, or high vacuum conditions. And the ultra small size unloaders are all customized with unconventional structures and special non-standard designs.　　Stainless steel unloaders can be used in places with high hygiene requirements such as food. They are easy to disassemble and clean, meeting high hygiene standards. Easy to operate, no dead spots.

　　快速清洗型旋轉閥廣泛應用于食品、醫藥、化工對衛生高要求場合，以及更換物料頻繁需要清理卸料的系統。按操作形式可分為滑桿式和快開式，易于快速清理葉腔中粘性物料，安裝方便?！　?.滑桿式旋轉閥：清洗前的拆卸。松開活動瑞蓋上的螺旋手柄，沿柱將瑞蓋和轉子一起拉出，松開軸端的螺旋手柄，取出轉子。　　2.快開門式旋轉閥：松開固定螺栓，打開端蓋門，抽出轉子，清洗后轉子推入殼體內，旋緊定位螺栓。【電話/微信咨詢：陳經理 18068546632】　　結構緊湊：采用行星轉動原理、純銅電機，輸入輸出在同一軸線上，而且有與電機直聯一體的獨特性，體積小，重量輕，因而結構緊湊造型美觀新樣。　　耐磨性高：運行可靠平穩，噪音低，故障少，壽命長，耐磨性高?！　∵^載能力強：卸料器具有過載能力強，耐沖擊慣性力矩小，適用于啟動頻繁和正反轉?！倦娫?微信咨詢：陳經理 18068546632】           《掃二維碼-添加 陳經理 微信-咨詢不銹鋼清洗型旋轉閥》　　Quick cleaning rotary valves are widely used in food, medicine, chemical industries with high hygiene requirements, as well as systems that require frequent cleaning and unloading of materials. According to the operating form, it can be divided into sliding rod type and quick opening type, which is easy to quickly clean viscous materials in the blade cavity and easy to install.　　1. Sliding rod rotary valve: disassembly before cleaning. Release the spiral handle on the activity cover, pull out the cover and rotor together along the column, release the spiral handle on the shaft end, and remove the rotor.　　2. Quick opening rotary valve: Loosen the fixing bolts, open the end cover door, extract the rotor, clean it, push the rotor into the housing, and tighten the positioning bolts.　　Compact structure: Adopting the principle of planetary rotation and a pure copper motor, the input and output are on the same axis, and it has the unique feature of being directly connected to the motor. It is small in size and light in weight, resulting in a compact structure and beautiful appearance.　　High wear resistance: reliable and stable operation, low noise, few faults, long service life, high wear resistance.　　Strong overload capacity: The unloader has strong overload capacity, low impact resistance inertia moment, and is suitable for frequent starting and forward and reverse rotation.

【風送滑桿式旋轉閥】耐高溫主要結構：外殼金屬;物料接觸部分：內襯陶瓷(也可碳化鎢、尼龍、四氟、特氟龍、聚氨酯、不銹鋼、合金等)。主要用于化工、食品、藥材、鋰電原料輸送。針對物料粘接，風力直吹轉子清理?？觳鹎謇?，快速復位。軸承外置式：有效的防止粉塵侵入軸承，增大設備適應較高溫度的使用范圍。驅動方式：鏈驅動/馬達直連驅動口?！倦娫?微信咨詢：陳經理18068546632】動力配置：擺線針輪減速機、Y系列電機(可按需方指定動力配置)。主要材料：不銹鋼304-316.陶瓷氧化鋁，碳鋼、鑄鐵、不銹鋼、鋁合金、鈦合金、陶瓷系列等。          《掃二維碼-添加 陳經理 微信-咨詢風送滑桿式旋轉閥》 Wind driven sliding rod rotary valveMain structure: metal shell; Material contact part: lined with ceramics (also tungsten carbide, nylon, PTFE, PTFE, polyurethane, stainless steel, alloys, etc.).Mainly used for transporting chemical, food, medicinal materials, and lithium battery raw materials.For material bonding, clean the rotor with direct wind blowing. Quick disassembly and cleaning, quick reset.External bearing: effectively prevents dust from entering the bearing and increases the equipment's adaptability to higher temperatures.Drive mode: chain drive/motor directly connected to the drive port.Power configuration: Cycloid pinwheel reducer, Y series motor (power configuration can be specified by the demand).Main materials: stainless steel 304-316. ceramic alumina, carbon steel, cast iron, stainless steel, aluminum alloy, titanium alloy, ceramic series, etc.

【風送式卸料閥】正壓輸送壓力范圍：2kg/cm2系統壓力或壓差。增大入口/出口：正方形，沒有截面尺寸對料流的限 制從而可達高產量。普通型：結構緊湊，占用空間小。軸承外置式：有效的防止粉塵侵入軸承，增大設備適應較高溫度的使用范圍?！倦娫?微信咨詢：陳經理18068546632】驅動方式：鏈驅動/馬達直連驅動口。動力配置：擺線針輪減速機、Y系列電機(可按需方指定動力配置)。材質選項：碳鋼、鑄鐵、不銹鋼、鋁合金、鈦合金、陶瓷系列等?！倦娫?微信咨詢：陳經理18068546632】風送式卸料閥主要用于化工、食品、藥材、原料輸送。           《掃二維碼-添加 陳經理 微信-咨詢風送卸料閥》Pressure range: 2kg/cm 2 system pressure or pressure difference.Increase inlet/outlet: Square, without cross-sectional size restrictions on material flow, thus achieving high yield.Ordinary type: compact structure and small space occupation.External bearing: effectively prevents dust from entering the bearing and increases the equipment's adaptability to higher temperatures.Drive mode: chain drive/motor directly connected to the drive port.Power configuration: Cycloid pinwheel reducer, Y series motor (power configuration can be specified by the demand).Material options: carbon steel, cast iron, stainless steel, aluminum alloy, titanium alloy, ceramic series, etc.Pneumatic discharge valves are mainly used for chemical, food, medicinal, and raw material transportation.

一款全尼龍星型旋轉閥，相比于傳統的304內襯工藝，噴涂碳化鎢四氟和陶瓷粉等工藝，全尼龍卸料閥更為優越，它不僅能保證閥的強度和耐磨性，還具備鎖風密閉的功能，讓物料更流暢，使用更精久。A fully nylon star shaped rotary valve, compared to traditional 304 lining process, spraying tungsten carbide tetrafluoroethylene and ceramic powder processes, the fully nylon discharge valve is superior. It not only ensures the strength and wear resistance of the valve, but also has the function of air locking and sealing, making the material smoother and more durable.這款改性尼龍旋轉閥采用了獨特的V型結構葉輪片，通過盛料后葉輪以低速旋轉的方式，讓物料根據自身重力進行卸料，在卸料過程中，物料可以密封，殼體與旋轉葉輪之間的間隙，實現了鎖氣功能，避免了氣體泄露的問題，全尼龍旋轉閥的兩端采用了氣密裝置，確保了閥的密封性，它的優越性能使得它在鋰電/化工/制藥行業得到了廣泛的應用?！倦娫?微信咨詢：陳經理18068546632】改性尼龍旋轉閥主要結構：殼體、葉輪、端蓋，采用改性尼龍。主要用于輸送鋰電池正極材料、磷酸鐵鋰、三元材料等。特點：改性尼龍比普通尼龍更耐磨、耐高溫?！倦娫?微信咨詢：陳經理18068546632】改性尼龍旋轉閥技術研發于2016年，批量生產于2018年，2020年更新第4代尼龍星型旋轉閥，目前有尼龍星型旋轉閥專 利。            《掃二維碼-添加 陳經理 微信-咨詢產品》This modified nylon rotary valve adopts a unique V-shaped structure impeller blade, which rotates at low speed after feeding, allowing the material to be unloaded according to its own gravity. During the unloading process, the material can be sealed, and the gap between the shell and the rotating impeller achieves gas locking function, avoiding gas leakage problems. The two ends of the all nylon rotary valve are equipped with airtight devices to ensure the sealing of the valve. Its superior performance has made it widely used in the lithium battery/chemical/pharmaceutical industries.The main structure of the modified nylon rotary valve is the shell, impeller, and end cover, which are made of modified nylon.Mainly used for transporting lithium battery cathode materials, lithium iron phosphate, ternary materials, etc.Characteristics: Modified nylon is more wear-resistant and heat-resistant than ordinary nylon.

　　螺旋輸送機/?絞龍輸送機/螺桿上料機專為塑料及粉體生產加工行業設計制造，本機與物料接觸部分全部采用不銹鋼制作，可與各種規格擠出機，高速混合機，塑料攪拌機配套使用，廣泛適用于各類粉狀，粒狀，回收破碎等物料的上(送)料用途。 可多機串聯使用，具有：自動控制加料，維修方便，安全可靠，提高工作效率等優點。接觸物料采用不銹鋼制作，輸送過程中原料完全不受污染，不帶入任何異物，能使生產過程中實現封閉自動化?！　he screw conveyor/auger conveyor/screw feeder is designed and manufactured specifically for the plastic and powder production and processing industry. The parts in contact with the materials are all made of stainless steel and can be used in conjunction with various specifications of extruders, high-speed mixers, and plastic mixers. It is widely used for feeding various types of powder, granular, recycled and crushed materials. It can be used in series with multiple machines and has the advantages of automatic feeding control, convenient maintenance, safety and reliability, and improved work efficiency. The contact material is made of stainless steel, and the raw materials are completely uncontaminated during the transportation process, without bringing in any foreign objects, which can achieve closed automation in the production process.【電話/微信咨詢：陳經理18068546632】　　【螺旋輸送機類型】：　　1、破拱.鎖氣.防沖料.組合螺旋送料機;　　2、雙向螺旋輸送機;　　3、精準喂料螺旋送料機;　　4、子母螺旋輸送機;　　5、提升螺旋輸送;　　6、雙螺旋輸送機;　　7、滑桿快拆螺旋送料機;　　8、高溫螺旋輸送機?！　piral conveyor type: arch breaking Lock the air Anti erosion material Combination spiral feeder; Bidirectional screw conveyor; Precision feeding screw feeder; Mother child screw conveyor; Enhance spiral conveying; Double helix conveyor; Sliding rod quick disassembly spiral feeder; High temperature screw conveyor.　　【主要材質】：不銹鋼食品拋光304.316.310.等.鈦合金.噴涂陶瓷.碳化鎢.四氟.陶瓷.尼龍.碳鋼.定制.   (總有一款適合您的需求)【電話/微信咨詢：陳經理18068546632】          《掃二維碼-添加 陳經理 微信-咨詢螺旋輸送機》　　Main materials: stainless steel food polishing 304.316.310. etc Titanium alloy Spray painted ceramics Tungsten carbide Tetrafluoroethylene Ceramics Nylon Carbon steel.   【電話/微信咨詢：陳經理18068546632】    【電話/微信咨詢：陳經理18068546632】       《掃二維碼-添加 陳經理 微信-咨詢螺旋輸送機》

　　根據物料輸送和下料口的溫度不同，因為溫度對機體膨脹有影響，以及對軸承和油封系統不利，我廠設計了耐高溫型外裝式結構關風機旋轉閥，它把運轉部分與物料接觸的箱體部分分離開來，可以安全地把軸承運轉和油封系統不受高溫影響而正常工作，此類產品不但耐高溫，還可以針對吸濕性物料和金屬性粉末的輸送和卸料，具有很好的效果。因為這類物體有穿透性，穿透油封裝置，物料進入軸承而損壞機械，正是有外裝的特點，它不會和物料接觸?！　⌒D(zhuǎn)閥主要結構：外殼金屬;物料接觸部分：內襯陶瓷(也可尼龍、四氟、特氟龍、聚氨酯、不銹鋼、合金等)。針對物料粘接，風力直吹轉子清理?？觳鹎謇恚焖購臀??？刹鹦度~輪：便于快速拆卸清洗旋轉閥的物料接觸面。驅動方式：鏈驅動/馬達直連驅動?！倦娫?微信咨詢：陳經理18068546632】   《掃二維碼-添加 陳經理 微信-咨詢鏈驅動高溫清洗型旋轉閥》

　　旋轉閥的工作原理主要涉及電動機驅動減速機，通過聯軸器或鏈輪使旋轉閥的轉子旋轉。在旋轉過程中，材料位于旋轉葉片的空間內，葉片的旋轉將材料帶到排出口，材料的自重使其流入輸送系統或儲藏室。這種工作方式使得旋轉卸料閥能夠均勻、連續地向輸料管供料，保證氣力輸出管內的氣體和固體物質保持穩定，從而確保氣力輸送系統的正常工作。同時，旋轉閥還具有鎖氣作用，能夠隔斷卸料閥上下部的氣壓。?【電話/微信咨詢：陳經理18068546632】　　高壓旋轉閥主要用于化工，食品，藥材，鋰電原料輸送?！　♂槍τ懈g物料、有害氣體，實現零泄漏、耐腐蝕、耐磨?！　「邏盒D(zhuǎn)卸料閥主要材質：不銹鋼、哈氏合金、鈦合金、鋁合金、各種合金。　　常州同得利提供鏈驅動、直連驅動多種安裝方式?！　∥夜臼冀K堅持“質量第 一、用戶至 上”的宗旨，服務于社會，誠信于業界，竭誠歡迎世界各地的業界好友光臨指導，洽談合作?！倦娫?微信咨詢：陳經理18068546632】      《掃二維碼-添加 陳經理 微信-咨詢鏈驅動高壓旋轉閥》　　The working principle of a rotary valve mainly involves an electric motor driving a reducer, which rotates the rotor of the rotary valve through a coupling or sprocket. During the rotation process, the material is located in the space of the rotating blades, and the rotation of the blades brings the material to the discharge outlet. The self weight of the material causes it to flow into the conveying system or storage room. This working method enables the rotary discharge valve to uniformly and continuously feed the conveying pipe, ensuring that the gas and solid substances in the pneumatic output pipe remain stable, thereby ensuring the normal operation of the pneumatic conveying system. At the same time, the rotary valve also has a locking effect, which can block the air pressure at the upper and lower parts of the discharge valve. ?　　High pressure rotary valves are mainly used for transporting chemical, food, medicinal materials, and lithium battery raw materials.　　To achieve zero leakage, corrosion resistance, and wear resistance for corrosive materials and harmful gases.　　The main materials of high-pressure rotary discharge valve are stainless steel, Hastelloy, titanium alloy, aluminum alloy, and various alloys.　　Changzhou Tongdeli provides multiple installation methods for chain drive and direct drive.　　Our company always adheres to the principle of "quality first, customer first", serves society, and is honest in the industry. We sincerely welcome industry friends from all over the world to visit and guide us, and negotiate cooperation.
