快速清洗旋轉閥制作精致、成功使用德、日技術制造之精華。產品拆裝靈活、易于清洗。主要用于化工、制藥、食品等行業高衛生標準的物料卸料及經常更換物料的場所工作?！　】刹鹦度~輪：便于快速拆卸清洗旋轉閥的物料接觸面?！　◎?qū)動方式：鏈驅動/馬達直連驅動?！　恿ε渲茫簲[線針輪減速機，Y系列電機(可按客戶指定動力配置)　　側快拆旋轉閥材質：不銹鋼304-316、四氟、尼龍、聚氨酯、陶瓷、特氟龍、鈦合金、鋁合金、不銹鋼。【電話/微信咨詢：陳經理 18068546632】　　側快拆式旋轉閥拆卸：松開固定螺栓，打開端蓋門，抽出轉子，清洗后轉子推入殼體內，旋緊定位螺栓。　　非電機側的閥體端蓋，可快速拆卸并作為清潔時的操作入口，拆卸時可由現場操作人員手動完成，無需特殊工具?！　√峁└鞣N標準的閥體表面處理標準，以滿足潔凈應用?！　〕Ｓ眯吞枺?L  DN150  轉速24轉/分   電機功率0.75KW　　6L  DN200  轉速24轉/分   電機功率0.75KW　　12L DN250  轉速24轉/分   電機功率1.1KW　　16L DN300  轉速24轉/分   電機功率1.5KW　　常州同得利機械廠擁有多年的研發生產/定制卸料閥旋轉閥的經驗，秉承質量第 一、用戶至 上的原則。我們的旋轉閥能夠處理鋰電池、鋼廠、電廠、水泥、礦山、環保、塑料、化工、食品和醫藥等行業的各種顆粒、片狀、塊狀物料、粘料、粉料、超微粉體等?！倦娫?微信咨詢：陳經理 18068546632】          《掃二維碼-添加 陳經理 微信-咨詢側快拆旋轉閥》　　The rapid cleaning rotary valve is exquisitely made, and successfully uses the essence of German and Japanese technology. The product is flexible in disassembly and easy to clean. Mainly used for unloading materials with high hygiene standards in industries such as chemical, pharmaceutical, and food, as well as working in places where materials are frequently replaced.　　Detachable impeller: facilitates quick disassembly and cleaning of the material contact surface of the rotary valve.　　Drive mode: chain drive/direct motor drive.　　Power configuration: Cycloid pinwheel reducer, Y series motor (can be configured according to customer's specified power)　　Material of side quick release rotary valve: stainless steel 304-316. PTFE, nylon, polyurethane, ceramic, PTFE, titanium alloy, aluminum alloy, stainless steel.　　Dismantling of side quick release rotary valve: Loosen the fixing bolts, open the end cover door, extract the rotor, clean it, push the rotor into the housing, and tighten the positioning bolts.　　The valve body end cover on the non motor side can be quickly disassembled and used as an operating inlet for cleaning. The disassembly can be manually completed by on-site operators without the need for special tools.　　Provide various standard valve body surface treatment standards to meet clean applications.
